QJAR big-payload 4 axis pick and place robot. It is with high speed and high stability….
Item No.: QJRB180-1
Payment: T/T
Product Origin: China
Shipping Port: Shanghai or designated port
Lead Time: 15-30 working days
| Model | QJRB180-1 | |
| Axis Number | 4 | |
| Payload | 180kg | |
| Repeat Positioning | ±0.5mm | |
| Max Armspan | 3153.7mm | |
| Motion Range | J1 | ±170º |
| J2 | ﹢95º,﹣47º | |
| J3 | ﹢112º,﹣20º | |
| J4 | ±360º | |
| J5 | _ | |
| J6 | _ | |
| Max Speed | J1 | 129º/s |
| J2 | 132º/s | |
| J3 | 132º/s | |
| J4 | 298º/s | |
| J5 | _ | |
| J6 | _ | |
| Allowable Torque | J4 | _ |
| J5 | _ | |
| J6 | _ | |
| Inertia Moment | J4 | 3.25kg.m² |
| J5 | _ | |
| J6 | _ | |
| Robot Body Weight | 1400kg | |
| Power Capacity | 17.5kVA | |
| Cabinet Size | 650*750*1150mm | |
| Cabinet Weight | 140kg | |
| Source | Three-phase five-wire | |
| Installing Form | Ground | |
